T/P Correct 30/50/80 Ultra
High-pressure Rotary Molding Machine
TOUGH PRESS series are high-tonnage rotary molding machines for large molds using extreme pressure in Industrial fields. These machines are especially developed for the molding of bath products, electronic parts, powdered metals and preliminary molding of resins.
Product Features
At the forefront of a dynamic powdered compaction industry stands KIKUSUI, having successfully introduced rotary molding machines to a variety of diverse applications. Through continuous dedication to improvement, KIKUSUI has made numerous contributions to the industry.
The engineering staff at KIKUSUI take pride in its TOUGHPRESS series machines. These machines innovatively departed from conventional design of previous machines, resulting in mechanical eccentric presses yielding pressure upward to 80 tons.
The TOUGHPRESS series is most suitable for use with powdered metals, ceramics and resins. Due to its rotary design, its high compression capability boasts unsurpassed production versatility.
-
Model TOUGHPRESS correct Type 3021SQ8EY 5019SM8GY 8017SQ8GY 80102L8GY No. of Stations 21 19 17 10 Type of tooling Key Roll Max pressure (kN) Pre 100/Main 300 Pre 300/Main 500 Pre 300/Main 800 Pre 200/Main 800 Max tablet dia (mm) 55 59 Turret speed (rpm) 3-10 8 or 10 Tablets/hr. 3,780-12,600 9,120 or 11,400 8,160 or 12,200 4,800 or 6,000 Filling depth (mm) 15-70 25-70 20-70 1st 5-15/2nd 5-30 Tablet thickness (mm) 10-40 0-18 Main Motor (kW) 18.5 22 Die Table PCD(mm) 700 900 Dimension (W*D*Hmm) 1,650x2,050x2,120 1,600x2,400x2,670 1,600x2,500x2,700 1,600x2,800x2,700 Weight (kg) 9,000 18,000 21,000 22,000 Model TOUGHPRESS correct Type 3021SQ8EY 5019SM8GY 8017SQ8GY 80102L8GY No. of Stations 21 19 17 10 Type of tooling Key Roll Max pressure (kN) Pre 100/Main 300 Pre 300/Main 500 Pre 300/Main 800 Pre 200/Main 800 Max tablet dia (mm) 55 59 Turret speed (rpm) 3-10 8 or 10 Tablets/hr. 3,780-12,600 9,120 or 11,400 8,160 or 12,200 4,800 or 6,000 Filling depth (mm) 15-70 25-70 20-70 1st 5-15/2nd 5-30 Tablet thickness (mm) 10-40 0-18 Main Motor (kW) 18.5 22 Die Table PCD(mm) 700 900 Dimension (W*D*Hmm) 1,650x2,050x2,120 1,600x2,400x2,670 1,600x2,500x2,700 1,600x2,800x2,700 Weight (kg) 9,000 18,000 21,000 22,000
